2012 5 AXLE CURTAINSIDE FULL TRAILER (E2001)
Serial Number: 1079
Trailer Specification
| Serial Number | 1079 |
|---|---|
| Model | E2001 |
| VIN | 7A9E20018C1023079 |
| GVM | 32000 |
| Registration | U421E |
| Fleet Number | NA |
| Axle Type | ROR LC/T9008 BMXA |
| Axle Rating | 9000 kg |
| Suspension Type | ROR CS9 |
| Suspension Ride Height | 280 mm |
| Brake System | WABCO EBS MULTIVOLT |
| Electrical | SUPERLITE AND HELLA LED |
| Coupling | 50 mm TOWEYE |
| Ballrace | BPW DK 90/14 |
| Body Type | CURTAINSIDE |
| Tyre Make & Model | MICHELIN XTE2 265/70 R19.5 |
| Wheels | ALCOA ALLOY |
Dimensions
| Trailer Length | 12770 |
|---|---|
| Drawbar Length | 1975 |
| Front Overhang | 1370 |
| Rear Overhang | 2370 |
| Wheelbase | 7025 |
Certification
| Fifth Wheel | N/A |
|---|---|
| King Pins | N/A |
| 1079 Wheel Alignment | 1079-Wheel-Alignment.pdf |
| 1079 SRT | 1079-SRT-Cert.pdf |
| 1079 Load Anchorage | 1079-Load-Anchorage-Cert.pdf |
| 1079 Drawbar | 1079-Drawbar-Cert.pdf |
| 1079 Chassis | 1079-Chassis-Cert.pdf |
| 1079 Brake coding | 1079-Brake-coding.pdf |
Important Information
| Wiring Diagram | Wiring_Diagram.pdf |
|---|---|
| Warranty & Insurance Information | Warranty__Insurance.pdf |
| Transpecs Wheel Nut Torque Specs | Transpecs_Wheel_Nut_Torque_Specs.pdf |
| Service Procedure | brake balance |
| ROR CS9 torque settings | ROR_CS9_torque_settings.pdf |
| Delivery Notice | IMPORTANT_NOTICE.pdf |
| Curtainsider Operation Warning | Curtainsider_Warnings.pdf |
Manuals
| Warranty Scope Wabco Products | Warranty_scope_Wabco.pdf |
|---|---|
| WABCO HC464 RIDE HEIGHT VALVE | WABCO-HC464-RIDE-HEIGHT-VALVE.pdf |
| ROR / Meritor Warranty Terms & Conditions | ROR_WARRANTY.pdf |
| Ride Height Adjustment Procedure | Ride_height_adjustment_procedure.pdf |
| BPW Ballrace Maintenance | BPW_Ballrace_Maintenance.pdf |
| Alcoa Alloy Wheel Service Manual | Alcoa_Alloy_Wheel_Service_Manual.pdf |
| Alcoa Alloy Warranty Form | Alcoa_Warranty_Form.pdf |
